Front Rail

8" tall; 3/16" sheet front rail (w/ holes laser cut in for optional bolt-on spare tire mount)

Frame

10" x 20 lb. Structural Channel

Deck

Flush Deck

Crossmembers

3" Channel on 16" Centers

Axles

(2) 10,000 lb. Dexter Oil Bath Straight Axles

Tire/Wheel

(4) 235-75R-17.5 (18-Ply) Radial Tires w/ 17.5 8-Hole Wheels

Hitch

2 5/16" Adjustable Coupler (Rated for 21,000 lb.) or Pintle Hitch

Brakes

Electric and Forward Self-Adjusting Brakes both axles

Fenders

(2) Extra Heavy 1/8" Formed Fenders

Fender Guards

Jack

(1) 12,000 b. Jost Spring Loaded Dropleg Jack

Stake Pockets

D-Rings

(8) D-Rings

Pallet Fork Holders

Ramps

5' Tube-Style Flip-up Ramps with Spring Assist; 18" Width; Adjustable leg

Floor

2 x 8 Treated Wood Floor, Flush Deck

Steel Diamond Plate Beavertail

Modular Wire Harness

12-Volt Breakaway Kit with Full Charge Indicator, Switch, and Battery Rubber Mounted Sealed LED Lights and Light Plug Holder

Reflector Tape

(2) 1/2" Grade 70 Safety Chains

Finish

Zinc Rich Primed and Powder Coated-Standard: Black, Red, Blue

Gray, Yellowstone
